drum bag inserter

Automatic drum bag inserter machine PE film barrel bag inserter machine M-type PE film pail bag inserter bucket Ploy bag inserter automatic can poly bag inserter  polybag in crate bag maker and inserter

Drum bag inserter feature:
The automatic bag inserter machine can automaticlly makes bag and inserts the bag from the tubular film roll into any type of the containers
From a tubular film roll, suction cups pick up the end of film and form the bag while the welding bar seals and cuts the bag.
Plastic bag inserter machine suitable for different sectors, such as: food, electronic products, stationery, plastic products, beverages and so on.
The automatic bag inserter machine can work with the case erector ,90 degree rotary truntable conveyor ,case packer ,and automatic bag folding machine ,automatic bag sealer and so on.

Drum Bag inseter technical and parameter:

² Width of the film: 460~800mm (Sum the Length of the carton +Width of the carton +150mm)

² Packing speed：7~10ctn/min

² Net weight 380kg

² Power：6Kw

² Power supply：110V220V/380V 50/ 60Hz , 1 / 3Phase

² Air pressure：0.6-0.8Mpa

² Max current：10A

² Machine dimension：L2200W1500H1800mm

² Cartons can be added at any time without stopping the machine;

² The bag will be sealed twice on the bottom, that could avoid the bag broken;

² Manually adjust to change the carton sizes (finishing in 2-3minutes);

² Advanced photoelectricity induction control system;

² Rationally designed, the forming, folding and sealing process are accomplished simultaneously;

² Widely applied on the electronic industry,toy and food industry;

² Heavy duty built, both steel and stainless steel types

² it adopt the PLC and HMI to control ,adopt the servo control system ,it is high accuracy

² Adopt the automatic postioning feeder type，it become automatic bag inseter movement,not need stop the machine

² It fit for the same kind carton box size pack in the same time ,if need change the carton box size ,

² it can manual adjustable,it need the ime is about 10-15mins

Drum Bag inserter core electrical component:

Sheet metal material:304 stainless , cold-rolled sheet 45# steeI ron box

Component material: 304 stainless , 45# steeI ron box,aluminum

Surface treatment of machined parts: galvanize or chromeplate extra stainless steel

drum bag inserter picture:
