pallet inverter /pallet rotator/ rotador de paleta/inversor de paleta/pallet turner



henopac pallet inverter or pallet turner is a machine that is used to turn over pallets whilst still loaded with products
With Unique design, the introduction of Germany advanced technology manufacturing, Lifting and rotating smoothly, very convenient, greatly improve the work efficiency
Use hydraulic motor HZBMR250,rotating smoothly, performance stable and low noise
HZ5KW Lifting pump station 1400r/min, displacement 10.0mL/r, strong,easy to work long hours.
Use High quality multiport valve HZ7060DL-3, flipping smoothly, safety highly. Can match any power according to different countries’requirements
Mainly used for cement, particle, plastic film, canned food, chemical industry, medicine…


Capacity      (kgs)   1500 customised
Pallet size    (mm) 1200*1100 customised
Goods Max.height(mm) 1150-1650 customised
Power supply  (V/HZ) 3 phase AC 380V 50Hz
Lifting motor  (Kw)  3
Turning motor  (Kw) AC1.5
Weight         (Kg) 3070
Over size(mm)L*W*H 2500*1200*2200
Lifting speed
full load/no-load mm/s   45/50
Falling speed
full load/no-load mm/s 50/45
Wooden case size 2500*2300*800 2400*1900*2000
